The Vapa Lebanon VC-9 Gas-Operated Burners deliver efficient and consistent radiant heat, making them an ideal choice for a wide range of industrial and commercial applications. Designed for adaptability, these burners can be seamlessly integrated into processes requiring precise and reliable radiant heating.
With their reliable performance, adaptability, and energy efficiency, the Vapa Lebanon VC-9 Burners are an essential tool for industries seeking effective and consistent radiant heat. These burners enhance productivity while maintaining safety and operational efficiency, making them the ideal heating solution across multiple sectors.
Upgrade your radiant heat processes with the VC-9 Gas-Operated Burners and experience precision, versatility, and reliability.
S NO. | MODEL NO. / NAME | Approx Weight | OVER ALL SIZE | INNER SIZE (BURNING AREA) | OPTIMUM WORKING PRESSURE | CONSUMPTION PER HOUR | RATED HEATED OUTPUT | |||||||||||
LENGTH | WIDTH | HEIGHT | LENGTH | WIDTH | ||||||||||||||
kgs | mm | ins | mm | ins | mm | ins | mm | ins | mm | ins | kg/cm2 | psig | kgs | lbs | kcal/hr | btu/hr | ||
1. | Vapa Lebanon (VC-9) S.S SHEET | 2.080 | 233.68 | 9.2 | 177.8 | 7 | 88.9 | 3.5 | 215.9 | 8.5 | 152.4 | 6 | 0.035-1 | 0.5-15 | 0.28-0.84 | 0.60-1.80 | 2,480-7,440 | 12,400-37,200 |
2. | Vapa Type Indian M.S SHEET | 1.840 | 228.6 | 9 | 177.8 | 7 | 88.9 | 3.5 | 190.5 | 7.5 | 139.7 | 5.5 | 0.035-1 | 0.5-15 | 0.28-0.84 | 0.60-1.80 | 2,480-7,440 | 12,400-37,200 |
3. | RECTANGLE S.S BODY | 0.740 | 228.6 | 9 | 177.8 | 7 | 76.2 | 3 | 177.8 | 7 | 127 | 5 | 0.035-1 | 0.5-15 | 0.25-0.75 | 0.50-1.50 | 2,200-6,700 | 11,000-33,000 |
4. | UGB C.I | 4.340 | 228.6 | 9 | 177.8 | 7 | 63.5 | 2.5 | 177.8 | 7 | 139.7 | 5.5 | 0.035-1 | 0.5-15 | 0.28-0.84 | 0.60-1.80 | 2,480-7,440 | 12,400-37,200 |
5. | IB 60 C.I | 7.960 | 482.6 | 19 | 127 | 5 | 76.2 | 3 | 444.5 | 17.5 | 88.9 | 3.5 | 0.035 | 0.5 | 0.38 | 0.85 | 4,280 | 17,000 |
6. | IB 40 C.I | 4.740 | 304.8 | 12 | 114.3 | 4.5 | 63.5 | 2.5 | 254 | 10 | 76.2 | 3 | 0.035 | 0.5 | 0.26 | 0.58 | 2,930 | 11,700 |
7. | IB 40 SHEET | 0.900 | 241.3 | 9.5 | 127 | 5 | 76.2 | 3 | 203.2 | 8 | 88.9 | 3.5 | 0.035 | 0.5 | 0.15 | 0.33 | 1,700 | 6,800 |
8. | SQUARE M.S SHEET+C.I | 2.060 | 190.5 | 7.5 | 190.5 | 7.5 | 50.8 | 2 | 152.4 | 6 | 152.4 | 6 | 0.035 | 0.5 | 0.12 | 0.31 | 1,370 | 5,400 |
9. | JUMBO (H.P) M.S SHEET | 6.700 | 457.2 | 18 | 241.3 | 9.5 | 88.9 | 3.5 | 431.8 | 17 | 203.2 | 8 | 0.035-1 | 0.5-15 | 0.73-2.20 | 1.56-4.68 | 6,450-19,400 | 32,300-96,700 |
