These burners are designed for optimal performance at a recommended pressure of 0.3 kg/cm² (4.5 psig). However, this pressure can be adjusted by ± 25%, allowing flexibility to meet specific heating requirements. The heat output of the burners will vary accordingly, ensuring precise control and efficiency in various applications.
These burners are ideal for applications where precise heat control is essential, such as in industrial processing, commercial kitchens, and other demanding environments. The ability to adjust pressure and heat output ensures that these burners can be tailored to meet specific requirements, enhancing efficiency and performance.
For more information on our versatile burners or to discuss your specific needs, contact us today. Optimize your heating applications with our high-quality burners designed for flexibility, precision, and reliable performance.
MODEL NO. | APPROX. WEIGHT | DIMENSIONS | OPTIMUM WORKING PRESSURE | CONSUMPTION PER HOUR | RATED HEATED OUTPUT | ||||||
LENGTH | HEAD DIAMETER | ||||||||||
kgs | mm | ins | mm | ins | kg/cm2 | psig | kgs | lbs | kcal/hr | btu/hr | |
M-22 | 1.18 | 203.2 | 8 | 63.5 | 2.5 | 0.3 | 4.5 | 0.9 | 2 | 10,100 | 40,000 |
M-35 | 1.920 | 215.9 | 8.5 | 76.2 | 3 | 0.3 | 4.5 | 1.58 | 3.5 | 17,650 | 70,000 |
M-50 | 2.560 | 241.3 | 9.5 | 88.9 | 3.5 | 0.3 | 4.5 | 2.24 | 5 | 25,250 | 1,00,000 |
M-78 | 1.920 | 299.7 | 11.8 | 111.7 | 4.4 | 0.3 | 4.5 | 3.56 | 7.8 | 40,350 | 1,60,000 |
M-140 | 9.340 | 609.6 | 24 | 177.8 | 7 | 0.3 | 4.5 | 6.3 | 14.0 | 70,560 | 2,80,500 |
